Crucial T705 Review (vs. T700): Turning PCIe 5.0 NVMe Performance to Eleven

Share what you're reading!

When it launched over a year ago, the Crucial T700 was undoubtedly the fastest consumer-grade SSD. Now, its successor, the Crucial T705—first announced on February 20, 2024, and officially available for purchase today—changes that.

In my testing, the new Crucial T705 edges out its predecessor as the fastest NVMe SSD on the market, making it an excellent alternative. For those looking for top performance, the drive is worthy of its comparatively high suggested retail cost—the street price will vary.

Still, the new internal SSD remains similar to its older cousin, and in real-world daily usage, chances are you won't notice the differences between the two. Both are incredibly fast.

Dong's note: I first published this post on February 20, 2024, as a preview and upgraded it to an in-depth review on March 12, 2024, after thorough hands-on testing.

The Crucial T705 PCIe 5.0 NVMe SSD
The 2TB Crucial T705 PCIe 5.0 NVMe SSD with heatsink and its retail box.

Crucial T705: Another hot PCIe Gen5 NVMe SSD

The Crucial T705 is very similar to the previous T700. The two share the same Phison E26 controller, capacities, and endurance.

The new drive, however, now has faster speed across the board thanks to Micron's new B58R 232L 3D TLC NAND flash memory, which outputs more million transfers per second (MT/s) than the one used in the T700. And in real-world testing, it proved to be indeed faster, as you'll note in the performance section below.

Still, the two drives are essentially the same. The table below shows their hardware specs.

Crcuial T705 vs T700 two fast NVMe SSDsCrcuial T705 vs T700 the two drives being tested on the same machine
Crucial T705 vs. T700: The two drives are very similar, and I used both during the testing.

Crucial T705 vs. T700: Hardware specifications

Micron Crucial T705Micron Crucial T700
Capacities1TB, 2TB, 4TB
Interface PCIe 5.0 x4
 NVMe 2.0
(compatible with PCIe 4.0/3.0)
Design M.2 (2280)
ControllerPhison PS5026-E26
NAND Flash MemoryMicron B58R 232L 3D TLC NAND
(2400 MT/s)
Micron 232-layer TLC NAND
(2000 MT/s)
SecurityAES-256 encryption, TCG Opal 2.01
Sequential Read
(up to)
1TB: 13600 MB/s
2TB: 14500 MB/s
4TB: 14100 MB/s
1TB: 11700MB/s
2TB: 12400MB/s
4TB: 12400MB/s
Sequential Write
(up to)
1TB: 10200 MB/s
2TB: 12700 MB/s
4TB: 12600 MB/s
1TB: 9500 MB/s
2TB: 11800MB/s
4TB: 11800MB/s
Random Read
(IOPS)
1TB: 1400K
2TB: 1550K
4TB: 1500K
1TB: 1350K
2TB: 1500K
4TB: 1500K
Random Write
(IOPS)
1TB: 1750K
2TB: 1800K
4TB: 1800K
1TB: 1400K
2TB: 1500K
4TB: 1500K
Endurance
(Terabyte Written)
600TBW (1TB)
1200TBW (2TB)
2400TBW (4TB)
SoftwareCrucial Storage Executive
Release DateMarch 12, 2024May 30, 2023
U.S. Suggested Price
(at launch)
1TB: $240 or $260 (heatsink)
2TB: $400 or $440 (heatsink) or $484 (white heatsink)
4TB: $714 or $730 (heatsink)
(Buy now)
$180 (1TB)
$400 (2TB)
$600 (4TB)
(add $30 for the heatsink versions)
(Buy now)
Warranty 5 years
Hardware specifications: Crucial T705 vs. Crucial T700
Crucial T705 topCrucial T705 underside
The top and underside of a Crucial T705 NVMe SSD with heatsink. The drive is also viable in a naked version.

A familiar SSD with fast speed and lots of heat

Like all PCIe 5.0 SSDs, the new Crucial T705 is expected to run hot. Generally, its performance will be throttled down when the drive gets hotter than 81oC (178oF), and at around 90oC (194oF), it might crash.

That's to say the heatsink version is required when you use the drive—or any PCIe 5.0 drive, for that matter—on a motherboard without a built-in heat-dissipating solution. The good news is that most PCIe 5.0 motherboards, not all, come with one for their M.2 slots. If so, you can get the naked version of the drive and save some money.

Other than that, the T705 shares the same feature set as its predecessor, including the helpful Storage Executive dashboard software (for Windows and Linux). The desktop dashboard app enables users to access the SSD's features, such as managing its security, over-provisioning, firmware updates, and more.

Crucial T705 Status
The Storage Executive app is an excellent dashboard software for managing the Crucial T705 and other NVMe SSDs from Micron.

Clearly, you need a computer with PCIe 5.0 to get the most out of the new Crucial T705, but the drive will work with all existing motherboards with PCIe 4.0 and PCIe 3.0. When used with an older PCIe version, the heat is less of an issue, but you'll also get slower performance.

And the performance is where the Crucial 705 shines.

Crucial T705: Excellent peformance

As you might have noted in the table above, the new T705 is slated to be faster than the T700 in sequential performances, with a margin of around 18% to 20% on paper. In random access performance, the two are similar.

And that proved to be the case in my testing. I tested the 2TB heatsink version for over 10 days and was thoroughly impressed. The new SSD screamed speeds.

Crucial T705 Read Or Write PerformanceCrucial T705 Read and Write Performance
The Crucial T705 delivers excellent sequential performance, even when used with PCIe 4.0

In real-world sequential tests, the T705 was stellar, easily topping charts with significant margins.

Specifically, it was the first I've used that could deliver over 10000MB/s of sustained speeds when reading or writing separately. When reading and writing simultaneously, it was the first to produce over 4000MB/s. Impressively, its performance didn't change much even when used with PCIe 4.0.

Crucial T705 IOPS Performance
The Crucial T705's random access (IOPS) performance was also impressive.

The drive's random access (IOPS) performance wasn't as jaw-dropping, but it also topped the charts in write performance. Its read wasn't the fastest, but it was still among the speediest.

It's worth noting, however, that in real-world, day-to-day usage, the T705 was essentially the same as its T700 predecessor. Yes, if you do a lot of raw data copy, you'll experience the benefit of reduced time thanks to the higher speed. However, for other types of work, such as content editing, gaming, or daily office tasks, the new drive made no difference. And that was because, for this type of general task, the T700 is already more than fast enough. There's just no room for improvement.

Crucial T705 PCIe 5.0 SSD's Rating

8.3 out of 10
Crucial T705 SSD
Performance
10 out of 10
Features
8 out of 10
Value
7 out of 10

Pros

Stellar performance with PCIe 5.0 or 4.0, especially in raw data transfer

Helpful Storage Executive desktop dashboard software

5-year warranty

Cons

Expensive

Runs hot

Conclusion

If you want the absolutely fastest NVMe SSD today, Micron's Crucial T705 PCIe Gen5 SSD is unquestionably the one. Get one today! However, considering the price, the slightly less-speedy Crucial T700, now with reduced costs, is a better deal. In most cases, you won't be able to tell them apart anyway.

If you want a PCIe 5.0 drive that balances performance and cost, the Samsung SSD 990 EVO will give you the best bang for your buck.
