Synology DS1823xs+: Powerful 2023 SMB NAS Server is Here

Share what you're reading!

Synology today released the DiskStationΒ DS1823xs+, an 8-bay server with built-in 10Gbps Ethernet capability.

Per Synology's naming convention, the xs+ signifies this is a high-end desktop server designed specifically for business users.

Still, running Synology's DiskStation Manager (DSM) operating system, it shares the Plus notion of non-xs servers, such as the DS923+, meaning it can host two Synology DX517 expansion units to up the total storage bay to eighteen.

Synology DS1823xs+: A server for serious business environment

It's important to note that as a business-oriented family, the xs+ series doesn't support the consumer-friendly Synology Hybrid RAID (SHR). Instead, the new server, like the precious DS1621xs+, only handles standard RAIDs.

The new 8-bay Synology DiskStation DS1823xs+ NAS server
The new 8-bay Synology DiskStation DS1823xs+ NAS server

Other than that, running the latest DSM 7.1, the new DiskStation DS1823xs+ comes with all common features of the OS, available in all DSM7-supported Synology servers. DSM has been the best NAS OSes.

You can also use the server as a host for network backup, data sharing/syncing, media streaming, IP camera NVR, virtual machines, and more.

Here are the highlights of what the new server can do, per Synology:

  • Over 3,100/2,600 MB/s sequential read/write performance supports large data transfer volumes and enables fast file sharing, syncing, and backup for multiple users.
  • Support for all-flash and hybrid storage arrays allows combining the I/O performance of SSDs and the efficiency of HDDs by designating M.2 NVMe and SATA SSDs as storage volumes or as read/write cache to speed up HDD volumes.
  • Built-in 10GbE connectivity is supplemented by a PCIe 3.0 expansion slot to boost bandwidth through optional 1/10/25GbE and Fibre Channel expansion cards.
  • Simple capacity expansion to 324 TB of raw storage is available whenever needed with two Synology DX517 Expansion Units.

In many ways, you can think of the DS1823xs+ as the serious upgrade of the DS1821+ that came out two years ago. The table below shows the differences between the two.

Hardware specifications: Synology DS1823xs+ vs DS1821+

Synology DiskStation DS1823xs Front Angle Synology DiskStation DS1821
ModelDS1823xs+DS1821+
CPUAMD Ryzen V1780B
Quad-core 3.35GHz
AMD RyzenV1500B
Quad-core 2.2 GHz
System Memory8 GB DDR4 4 GB DDR4
Max Memory32 GB
(16 GB x 2 slots)
32 GB
(16 GB x 2 slots)
Dimensions6.53 x 13.5 x 9.57 in
 (166 x 343 x 243 mm)
6.53 x 13.5 x 9.57 in
 (166 x 343 x 243 mm)
Weight13.7 lbs (6.2 kg)13.23 lbs (6.0 kg)
Drive Bays88
Expansion Support2x DX5172x DX517
Drive Interface2.5 or 3.5 SATA Drives,
Hot-swappable
2.5 or 3.5 SATA Drives,
Hot-swappable
Maximum Capacity
(at launch)
144 TB
(8x 18TB drives)
128 TB
(8x 16TB drives)
Built-in M.2 SlotsTwo
(cache or storage pool)
Two
(cache only)
RAID TypesSynology RAID F1, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, and RAID 10SHR, Basic, JBOD,
RAID 0, RAID 1, RAID 5,
RAID 6, RAID 10
Ports / Interfaces1x RJ-45 10GbE LAN,
3x RJ-45 1GbE LAN,
1x RJ-45 1GbE Management port,
3x USB 3.0,
2x eSATA
4x RJ-45 1GbE LAN,
 3x USB 3.0,
2x eSATA
PCIe Expansion1x Gen 3 x8 PCIe slot1x Gen 3 x8 PCIe slot
Add-in-card Support
(not included)
10GbE Add-on NIC card:
E10G18-T2
E10G18-T1
E10G21-F2
10GbE Add-on NIC card:
E10G18-T2
E10G18-T1
E10G21-F2
Operating SystemDSM 7.1 (and later)DSM 6 (and later)
File System
(Internal / External)
Btrfs, EXT4 /
Btrfs, EXT4,
EXT3, FAT,
NTFS, HFS+,
exFAT (app required)
Btrfs, EXT4 /
Btrfs, EXT4,
EXT3, FAT,
NTFS, HFS+,
exFAT (app required)
Suggested Retail Price
(at launch)
$1799.99 $949.99
Warranty5 years3 years
Synology DS1823xs+ vs DS1821: Hardware specifications

It's worth noting that while you can generally perform an easy migration from one Synology NAS to another by moving the internal hard drives, that's only possible if the source server uses a RAID configuration it supports.

Specifically, if your old server is using SHR, which is popular, easy migration to the DS1823xs+ is not possible. But if you've been using the DS1621xs+, moving to the latest server will be seamless.

Synology DiskStation DS1823xs FrontSynology DiskStation DS1823xs Back
The front and back of the Synology DiskStation DS1823xs+

NVMe-as-storage support

Another significant notion about the DS1823xs+ is, like the DS923+, it supports NVMe SSDs both for caching and storage pools. It's the first in the xs+ family that gets this capability.

Consequently, users can get a superfast volume out of it for frequently-access data, such as a database or network video editing.

Availability and pricing

Synology says the DiskStation DS1823xs+ is available now with the suggested price of $1799.99 (diskless). You can get one today or check out the review of the DS1821+ for some reference -- below is its rating.

Synology DiskStation DS1821+'s Rating

9 out of 10
Synology DS1821
Performance
9 out of 10
Features
9.5 out of 10
Design and Setup
9 out of 10
Value
8.5 out of 10

Pros

Powerful AMD CPU delivers fast and reliable performance

Robust DiskStation Operating System with tons of practical home and business applications, including Virtual Machines

Straightforward and consistent setup, upgrade, and management

Built-in M.2 NVMe slots

Eight built-in drive bays, lots of network storage options

Quiet operator

Cons

Expensive RAM upgrade

No built-in 10Gbps port (adapter required)

Only two camera licenses included

A bit pricey
