Asus RT-AX88U vs. RT-AC88U: The Same Router of Two Wi-Fi Standards

Share what you're reading!

Asus RT-AX88U vs. RT-AC88U is an interesting comparison since they are of two different Wi-Fi standards.

Right off the bat, it seems the former, the Wi-Fi 6 version, is a straightforward replacement of the Wi-Fi 5 counterpart. But is that the case? Find it all out in this post.

Asus RT-AX88U vs. RT-AC88U
The Asus RT-AX88U is almost identical to the RT-AC88U.

RT-AX88U vs. RT-AC88U: Similarities

Just take a good look at them. They are almost identical. Indeed, these two routers share the same design, dimensions, weight, number of network ports (eight LANs and one WAN), and antennas. And there's more.

On the inside, they both have the same set of features, including gaming, online protection, QoS, and so on. The two can also work together to create an AiMesh Wi-Fi system. (In this case, it's best to use them via a wired backhaul.)

Most importantly, you can put Merlin firmware on both and turn them into much better Wi-Fi machines than what you get out of the box. The support for Merlin is among the main reason I'd consider these two.

Asus RT-AX88U vs. RT-AC88U: Hardware specifications

NameASUS AX6000 Dual-Band
Wi-Fi 6 Router
ASUS AC3100 Dual-Band
Wi-Fi 5 Router
ModelAsus RT-AX88UAsus RT-AC88U
Wi-Fi TechnologyDual-Band Wi-Fi 6 (802.11ax) AX6000Dual-Band Wi-Fi 5 (802.11ac) AC3100
Chipset ManufacturerBroadcomBroadcom
2.4GHz Wi-Fi Specs4x4 Wi-Fi 6: up to 1148 Mbps4x4 Wi-Fi 5: up to 1000 Mbps
5GHz Wi-Fi Specs4X4 Wi-Fi 6: up to 4833 Mbps4x4 Wi-Fi 5: up to 2167 Mbps
Supported Wi-Fi Standards802.11a/b/g/n/ac/ax802.11a/b/g/n/ac
AP ModeYesYes
Mesh-readyYes (AiMesh)Yes (AiMesh)
Channel Width Support20/40/80/160 MHz20/40/80 MHz
Gigabit LAN Ports8x Gigabit LAN, 1x Gigabit WAN8x Gigabit LAN, 1x Gigabit WAN
Multi-Gig PortsNoneNone
Link AggregationYes (LAN 1 and LAN 2)Yes (LAN 1 and LAN 2)
USB2 x USB-A USB 3.01x USB 2.0, 1 x USB 3.0
Mobile AppAsus RouterAsus Router
QoSYes (Excellent)Yes (Excellent)
Built-in Online ProtectionYesYes
Parental ControlYesYes
Merlin Firmware SupportYesYes
Gaming FeaturesWTFast Gamers VPN,
Automatic Port-forwarding
and QoS
WTFast Gamers VPN,
Automatic Port-forwarding
 and QoS
Processing Power1.8 GHz quad-core CPU,
 256MB Flash, 1GB RAM
1.4 GHz dual-core CPU,
128MB Flash, 512MB RAM
Dimensions11.8 x 7.4 x 2.4 inches
(30 x 18.8 x 6.04 cm)
11.8 x 7.4 x 2.4 inches
(30 x 18.8 x 6.04 cm)
Weight2.1 lbs (945 g)2.1 lbs (945 g)
Hardware specifications: RT-AX88U vs. RT-AC88U

RT-AX88U vs. RT-AC88U: Differences

The most significant difference between the two is the fact the RT-AX88U is a more powerful router. For one, it uses Wi-Fi 6. It also has a faster quad-core CPU and doubles the amount of RAM and flash memory.

The RT-AX88U also has two USB 3.0 ports (instead of one 2.0 port) and, in my testing, delivered much faster network storage performance when hosting a portable SSD.

In many ways, the RT-AX88U supersedes RT-AC88U as it's intended to be. However, the lack of a multi-gig port means, in reality, you likely won't see much difference between the two in terms of network Wi-Fi performance.

RT-AX88U vs. RT-AC88U: Performance and ratings

It's expected that the RT-AX88U would outdo the RT-AC88U, and, for the most part, it did in my testing. However, having no multi-gig port, it wasn't that much faster when working with Wi-Fi 5 clients.

By the way, I initially tested the RT-AC88U using only Wi-Fi 5. There was no Wi-Fi 6 when I reviewed it, and it doesn't have support this standard anyway. (Wi-Fi 6 clients do work with Wi-Fi 5 broadcasters).

But like all Wi-Fi 5 routers, it works with Wi-Fi 6 clients, or the other way round—Wi-Fi 6 clients work with Wi-Fi 5 broadcasters.

In any case, for this post, I did some additional tests using 2x2 Wi-Fi 6 clients, which connected to the router at 867 Mbps of negotiated speed. That's the ceiling speeds of 2x2 Wi-Fi 5.

By the way, both routers can host network storage via a portable drive. But of the two, only the RT-AX88U can work as a mini NAS server. It had much faster NAS speeds, as shown here, thanks to the higher hardware specs.

Asus RT-AC88U's Rating

9 out of 10
Asus RT AC88U 1
9 out of 10
9.5 out of 10
Design and Setup
8.5 out of 10
9 out of 10


Fast Wi-Fi performance with excellent coverage

Tons of valuable features, including the ability to guard the network against online threats

Eight LAN ports with Dual-WAN and Link Aggregation

Excellent support for Asus's AiMesh

Merlin firmware support


Awkwardly placed USB 3.0 ports

Slow network storage speed when coupled with an external hard drive

RT-AX88U vs. RT-AC88U

Asus RT-AX88U's Rating

8.4 out of 10
RT AX88U 2
8.5 out of 10
8.5 out of 10
Design and Setup
8.5 out of 10
8 out of 10


Fast Wi-Fi performance

Tons of useful features

Eight network ports with Dual-WAN and Link Aggregation

Universal setting backup and restoration

Fast network-attached storage speed when coupled with an external drive.

Merlin firmware support


No multi-gig network port

Buggy firmware (at review)

Which to get

In many ways, the RT-AX88U is better than the Wi-Fi 5 counterpart. But it's also much more expensive while sharing the same feature set.

So if you're still having a lot of Wi-Fi 5 and legacy clients, the RT-AC88 is a better choice. Put the Merlin firmware on it, and you'll be amazed by what it has to offer.

And then, when you're ready to upgrade to Wi-Fi 6, keep it. It'll still work great as an AiMesh node, especially if you have wired your home with network cables.

The RT-AX88U is also a great router. But unfortunately, the lack of multi-gig network ports means you won't almost see its full potential. For that reason, you should consider the more affordable yet multi-gig-ready RT-AX86U instead.
