Zyxel NWA130BE Access Point Review (vs. WBE660S): Wi-Fi 7 Upgrade Made Affordable

Share what you're reading!

If you're thinking of upgrading your home or office to Wi-Fi 7 but have been taken aback by the WBE660S's cost and large physical size, the NWA130BE BE11000 Wi-Fi 7 Triple-Radio NebulaFlex Access Point, first announced on March 4, 2024, would be the answer.

Each of these Wi-Fi 7 access points can work as a standalone broadcaster via local web-based management or as part of a cloud-based Nebula system. This review looks at the NWA130BE primarily as the former role.

In more ways than one, the new AP is a mini version of its older and more potent cousin. Still, at less than a third of the costโ€”its current street price is around $180โ€”the NWA130BE is an excellent and easy way to upgrade a network to Wi-Fi 7. Consider one today!

Dong's note: I first published this post as a preview on March 4, 2024, and updated it to an in-depth review after weeklong hands-on testing.

Zyxel NWA130BE and its retail box
The new Zyxel NWA130BE is a standard Wi-Fi 7 access point.

Zyxel NWA130BE: A sensible Wi-Fi 7 access point

The reason for the significantly lower cost is the hardware. The NWA130BE is modest in Wi-Fi specs, featuring the 2x2 tier of the new standard or half the bandwidth of the older model. It also has the entry-level Multi-Gig Ethernet, 2.5Gbps, to match.

But before you get disappointed, 2x2 Wi-Fi 7 is plenty fast, and generally, the specs of the receiving end. Like the case of Wi-Fi 6 and 6E, so far, we've had only 2x2 Wi-Fi 7 clients.

That is, in terms of real-world Wi-Fi speed on a single device, the new NWA130BE is likely similar to the much more expensive WBE660S, which has double the bandwidth.

Physically, the new two APs share the same designโ€”both are rectangle boxes with curved cornersโ€”but the NWA130BE is just about half the volume of the WBE660S. So, yes, the new access point is very much the mini version of the older model.

The table below shows the hardware specs of the two.

Zyxel NWA130BE vs. WBE660S the former is significantly smallerZyxel NWA130BE vs. WBE660S ports
Zyxel NWA130BE vs. WBE660S: Both share the same rectangle shape, but the former is significantly smaller, with ports located on one of its length sides instead of its width. It also uses a traditional round power port instead of the newer USB-C port.

Zyxel NWA130BE vs. WBE660S: Hardware specifications

Zyxel NWA130BE Wi-Fi 7 Access Point MountedZyxel WBE660S
NameZyxel NWA130BE BE11000 Wi-Fi 7 Triple-Radio NebulaFlex Access PointZyxel WBE660S BE22000 Wi-Fi 7 Triple-Radio NebulaFlex Pro Access Point
ModelNWA130BEWBE660S
Wi-Fi StandardsTri-band BE11000Tri-band BE22000
Broadcasting PowerUS (2.4GHz/5GHz/6GHz): 29/28/23dBm
 EU (2.4GHz/5GHz/6GHz): 19/25/22dBm
6 GHz Speeds
(channel width)
2x2 BE: Up to 5765 Mbps
(20/40/80/160/320MHz)
4x4 BE: Up to 11530 Mbps
(20/40/80/160/320MHz)
5 GHz Speeds
(channel width)
2x2 BE: Up to 4323 Mbps
(20/40/80/160MHz)
4x4 BE: Up to 8646 Mbps
(20/40/80/160MHz)
2.4 GH Speeds
(channel with)
2x2 BE: Up to 688 Mbps
(20/40MHz)
4x4 BE: Up to 1376 Mbps
(20/40MHz)
Number of SSIDs8
(single or multiple bands)
Operating ModeStandalone or via
Controller/Nebula Cloud-managed
(Nebula account required)
Roaming StandardPre-authentication, PMK caching and 802.11r/k/v
Backward Compatibility802.11/axe/ax/ac/n/g/a/b
Power over Ethernet (PoE)802.11at (PoE+)802.11bt (PoE++)
PoE Power DrawTBD41W
Injector IndudedNo
DC inputDC 12 VUSB PD 15 VDC 3 A
(USB-C port)
Adapter IncludedNo
Multi-Gig port1 x 2.5GBASE-T PoE+ (uplink)
1 x 2.5GBASE-T
1 x 10GBASE-T PoE++ LAN (uplink)
Gigabit Portnone1 x 1GBASE-T
Wireless Security MethodsWEP/WPA/WPA2/WPA3
AuthenticationIEEE 802.1X/RADIUS
Access ManagementL2-isolation/MAC filtering/Rogue AP detection
Mobile AppZyxel Nebula
Dimensions (W x D x H)9.84 x 6.30 x 1.85 in
(250 x 160 x 47mm)
12.21 x 7.01 x 2.21 in
(310 x 178 x 56 mm)
Weight1.79 lbs (808 g)3.11 lbs (1412 g)
ProcessorQualcomm 4-Core CPU
Operating EnvironmentTemperature: 0ยฐC to 45ยฐC/32ยฐF to 113ยฐF
Humidity: 10% to 90% (non-condensing)
Release DateMarch 4, 2024October 17, 2023
WarrantyLifetime
US Price
(at launch)
$179.99$599.99
Hardware specifications: Zyxel NWA130BE vs. WBE660S
Zyxel NWA130BE TopZyxel NWA130BE underside
The top and underside of the Zyxel NWA130BE Wi-Fi 7 access point.

No injector or power adapter is included

The NWA130BE allows for an easy path to upgrade an existing network to Wi-Fi 7. Specifically, if you have a non-Wi-Fi router or one of an older standard, a single unit of the NWA130BE will turn the system Wi-Fi 7-ready.

Before that, though, it's worth noting that the new AP doesn't include a power adapter or PoE injector. Instead, you need a PoE+ (802.3at) switchโ€” the Zyxel XS1930-12HP or the newly announced XMG1915 Seriesโ€”to use it. Or a single standard PoE+ injector will do as long as it features 2.5Gbps ports. The support for 8023at means you won't need to invest in the top-tier PoE++ equipment.

Alternatively, you can find a standard DC 12 V adapter to power it, though that's not ideal, considering this is a piece of hardware designed for wall or ceiling mounting.

While it's disappointing that no power adapter or PoE injector is included, that's generally the case with most business access points.

A standard Wi-Fi 7 access point

As a Wi-Fi 7 broadcaster, the NWA130BE features extra-wide 320MHz channels and 4K QAM. It'll also get Multiple Link Operation (when available) and, per Zyxel, has an RF-first Designโ€”it incorporates an advanced RF filter to eliminate interference between 5GHz and 6GHz bands and a 4G/5G interference filter to assure seamless coexistence with 4G/5G cellular networks.

Like the WBE660S, the NWA130BE has two management options: the built-in web-based user interface and the Nebula cloud-based portal. Unless you have multiple units and want to use them as a system, the former is generally ideal. It fits most cases where a single unit is enough regarding coverage, and it's also the case I used to test most access points.

Nebula comes in two flavors: free and Pro. The latter requires a 39.99/year per device subscription, though the former is more than enough for any home or small business.

Zyxel NWA130BE Wi-Fi SSIDsZyxel NWA130BE Wi-Fi Settings
The NWA130BE has a standard local web user interface, common among Zyxel access points, with lots of customization and Wi-Fi settings.

Self-explanatory local web user interface with lots of settings

To set up the NWA130BE, you first need to connect it to the network via an injector or a PoE+ switch. After that, navigate a browser on a network computer to its IP address, and the rest is self-explanatory.

Like all APs, the NWA130BE's local IP address is given out by your routerโ€”it's static like the case of a router. Still, as described in this post on the IP address, it's relatively easy to find a connected device's local IP.

In my case, as shown in the screenshots, the NWA130BE uses the 192.168.88.1900 addressโ€”yours will vary. The AP's default password for the admin account is 1234, which you'll need to change the first time you log in.

Once logged in, you'll be greeted by a standard yet comprehensive menu-based web interface with many settings. The APs can handle up to eight SSIDs. You can use each for one, two, or all three of its bands and customize them with in-depth Wi-Fi settings. In most cases, you only need three SSIDs.

And after that, you can leave the rest alone. The Wi-Fi network is now ready.

The Zyxel NWA130BE Wi-Fi 7 Access Point in action
Here's the Zyxel NWA130BE Wi-Fi 7 Access Point being tested.

Zyxel NWA130BE: Reliable performance

I tested the Zyxel NWA130BE for over a week and was generally happy with its performance.

The AP's range was similar to that of the WBE660S, but its sustained rates were clearly lower due to the modest Wi-Fi specs. That said, a single unit can generally cover about 2000 ft2 (186 m2) with decent Wi-Fi performance throughput, but your mileage will vary. It also passed my 3-day stress test with no disconnection.

Zyxel NWA130BE Wi-Fi Long Range PerformanceZyxel NWA130BE Wi-Fi Close Range Performance
Zyxel NWA130BE's wireless performance when hosting clients of different Wi-Fi standards.

In terms of throughput speeds, the NWA130BE's sustained rates are in the low Gig+ rangeโ€”between 1Gbps and 1.5Gbpsโ€”even at relatively short distances. It was plenty fast but below the average among Wi-Fi 7 broadcasters I've tested. Further out, the rates were consistently reduced to below Gigabit, as shown on the charts.

Since this is the first access point with two Multi-Gig ports, I also tested these ports' wired performance, and they performed as expected, sustaining at over 2200Mbps or the general speeds of 2.5Gbps after overhead.

Zyxel NWA130BE Multi-Gig Wired Performance
Zyxel NWA130BE's Multi-Gig wired performance.

Other than that, the Zyxel NWA130BE ran completely silent and procured very little heat, even during extended heavy operations.

Zyxel NWA130BE Wi-Fi 7 Access Point's Rating

8 out of 10
Zyxel NWA130BE
Performance
7.5 out of 10
Features
8 out of 10
Design and Ease of Use
8.5 out of 10
Value
8 out of 10

Pros

Wi-Fi 7 support with reliable Gigabit-class performance; good coverage

Dual 2.5Gbps ports

Compact, mount-ready design; full local web user interface; generous free-tier cloud-based management

Cons

No power adapter or PoE injector is included

Mid-range Wi-Fi 7 specs

Conclusion

The Zyxel NWA130BE BE11000 Wi-Fi 7 Triple-Radio NebulaFlex Access Point doesn't have anything earth-shattering. It's a mid-tier Wi-Fi 7 access point that gets the job done.

However, at less than $180, it is an excellent upgrade for those wanting to move to Wi-Fi 7 without digging a hole in their wallet while keeping their existing network largely intact.

And that's a good thing. Consider one today!
