This post is a collection of the best seven gaming routers, and their worthy alternatives picked among those I've reviewed.
There's no concrete definition of a "gaming router," but all listed below meet at least two of my qualifying criteria.
Any of these mentioned here will give you an edge in getting connected, plus the much-needed placebo effect. Among other things, you know you're already well-equipped, possibly even better-geared than the other guy.
Dong's note: I first published this post on January 29, 2021, and updated it on March 20, 2023, with up-to-date options.
Best gaming routers for 2023: The list
All routers on this list are excellent for general use. On top of that, they collectively check all the gaming boxes.
They are listed here on reviewed orders with the latest on top -- the number in front of their name is not for ranking but just numerical.
7. RadiX AXE66000: MSI’s First (gaming) router in years
In case you didn't read the intro: This is the latest member of this list. The number is not the ranking.
The Wi-Fi 6E RaiX AXE6600 and its Wi-Fi 6 cousin RadiX AX6600 are the first Wi-Fi router from MSI in many years. And they are both marked as gaming routers.
On the inside, their gaming features are all QoS-based. So, the two are similar to TP-Link's Archer GX90 below, as both don't have the most comprehensive set of gaming-related features.
But you'll be able to play games with them just fine. And the RadiX AXE6600 tops that off with an incredible set of Mystic Light. It's big on the bling department.
Similar alternative: MSI Radix AX6600
MSI Radix AXE6600's Rating
Pros
Top Wi-Fi 6E specs; cool Mystic Light; Reliable Wi-Fi performance
Lightweight yet robust web user interface; helpful mobile app
Supports all standard home network settings, deep Wi-Fi customization
Nice design, low power consumption
Cons
Only one 2.5Gbps port; mediocre 5GHz specs
Thin on gaming and network protection features; no Dynamic DNS, Link Aggregation, or Dual-WAN
Mystic Light requires a PC app; Network storage requires SMBv1 with lackluster performance
6. Asus ROG Rapture GT6: The first gaming canned mesh system
The ROG Rapture GT6 is the only purposed-built gaming mesh system in this list -- it's about the only one in the market.
While you can build a mesh system starting with an Asus AiMesh router, including any of those mentioned below, the GT6 is an excellent choice if you're into a wireless mesh with built-in support for gaming.
Asus ROG Rapture GT6's Rating
Pros
Excellent Wi-Fi performance and coverage, UNII-4 support
Tons of useful features and settings, including built-in gaming features
AiMesh 2.0 full support, helpful mobile app, no login account required
Compact and good looking, USB port
Cons
Single 2.5Gbps WAN-only port
Buggy (initial release) firmware
Slow network storage performance when hosting a USB portable drive; not wall-mountable
5. Asus ROG Rapture GT-AXE16000: Representing Asus’s top-tier gaming routers
The Asus GT-AXE16000 is the pinnacle of home networking, and gaming is just the icing on the cake. This is the ultimate router you can safely get if you can afford it.
Asus has the largest selection of gaming routers -- not all are listed here, but you can read about them in this post on Asus Wi-Fi broadcasters.
The GT-AXE16000 is currently the best in Asus's ROG Rapture family. But the following are also worthy alternatives:
Asus ROG Rapture GT-AXE16000's Rating
Pros
Powerful hardware, Quad-band with Wi-Fi 6E support, three Multi-Gig ports (one 2.5Gbps and two 10Gbps)
Stellar performance throughout
Excellent set of game-related, online protection and monitoring features, full AiMesh 2.0 support
Unmatched port flexibility, including interchangeable WAN, Dual-WAN, and LAN/WAN Link Aggregations
Beautiful ROG Aura lighting
Cons
Expensive, 10Gbps ports' sustained rates and NAS performance (when hosting a storage device) could be better
Awkward backhaul band design in a wireless AiMesh setup, no UNII4 (5.9GHz) support, no SFP+
Bulky design, not wall-mountable
4. TP-Link Archer GX90: Representing gaming routers that mostly “look the part”
The GX90 is TP-Link's latest Wi-Fi 6 approach to gaming routers. It is also somewhat of a pseudo-gaming machine since it doesn't have any specific game-related novelty -- it has a nice look plus a comprehensive QoS feature.
The GX90's similar alternative: Archer AX11000
TP-Link Archer GX90's Rating
Pros
Fast and reliable Wi-Fi performance
2.5 Gbps WAN/LAN
Excellent feature set and network settings
Robust full web user interface
Nice design and comparatively affordable
Cons
Thin on gaming
Single Multi-Gig port; no Dual-WAN or Link Aggregation
USB-based storage performance could be better
3. Asus ROG STRIX GS-AX5400: Representing Asus’s budget gaming routers
The GS-AX5400 is an excellent new (gaming) router. It represents the new ROG STRIX product line.
Similar alternatives:
Asus ROG STRIX GS-AX5400's Rating
Pros
Excellent overall performance
Complete AiMesh 2.0 support, including system-wide Guest network
Robust web interface, well-designed mobile app, no login account required
Lots of useful features, including those for gamers
Cool-looking front-facing AURA Game light
Cons
No Multi-Gig port or Gamer VPN (WTFast)
Performance as a NAS server could be better
The ROG logo doesn't light up, a bit boring
2. Netgear XR1000: Representing Netgear’s DumaOS-based routers
The XR1000 is a Wi-Fi 6 upgrade to the Wi-Fi 5 version XR500. It's the second gaming router based on game-centric DumaOS firmware and has fantastic gaming features, including an improved Geo-Filter with polygon mode and Ping heatmap.
Similar alternative: Any DumaOS-based router, such as the Nighthawk XR500
Netgear Nighthawk XR1000's Rating
Pros
Sophisticated game-centric firmware
Fast Wi-Fi speeds and reliable performance
Robust web UI, beautiful hardware design
Useful mobile app, wall-mountable
Cons
Expensive but underpowered - items of the web interface can take a long time to fully load
Limited Wi-Fi settings, sluggish user interface
Mobile app can't manage any gaming features
No multi-gig port, Dual-WAN, or Link Aggregation
Online protection and VPN require subscriptions
Buggy -- firmware needs some serious updates; no mesh option
1. Asus RT-AX82U: Representing Asus’s RT family
In case you didn't read the intro: This is the first member of this list. The number is not the ranking.
The Asus RT-AX82U uniquely has fantastic-looking programmable front lighting that will turn heads! If you're into bling, this is the gaming router for you.
The RT-AX82U represents a few general routers -- not part of the ROG Rapture or ROG Strix families mentioned above -- with built-in gaming features.
Similar alternatives include:
Asus RT-AX82U's Rating
Pros
Excellent performance
Beautiful design with tons of helpful networking, game-related features, and settings
Robust web UI, well-designed mobile app
Comparatively affordable
Cons
No support for WTFast Gamer VPN
No multi-gig network port
Network storage performance (when hosting a portable drive) could use some improvement
Not wall-mountable
Best gaming routers for 2023: Hardware specifications and Wi-Fi performance
I tested all of these routers the way I do all Wi-Fi broadcasters. I also tried their gaming features via wired and wireless connections without a retail or mesh extender.
It's best to use a game console (or PC) via a wired connection. If you have to use Wi-Fi, make sure the device connects directly to the very first broadcaster of your home if you have more than one Wi-Fi hub.
Note on gaming and Wi-Fi
For the best online experience -- including online gaming or whenever you want to make sure the connection is the most reliable and with the lowest latency -- it's always best to get your home wired.
After that, connect your gaming rig to your network via a cable. No matter how fast, Wi-Fi is always less ideal and will put a few extra milliseconds, or even a lot, on your broadband's latency.
Reliability and low latency are more critical than fast speeds in gaming or any real-time communication applications. So it's more a question of wired vs Wi-Fi than Wi-Fi 5 vs Wi-Fi 6.
But we can't use wires all the time. That said, the rule in Wi-Fi for gaming is to avoid multiple hops.
Specifically, here is the order of best practices when connecting your gaming device to the network via Wi-Fi:
- Use a single broadcaster -- just one Wi-Fi router or access point.
- If you must use multiple broadcasters (like a mesh system), then:
- Use a network cable to link them together (wired backhaul).
- If you must use a wireless mesh, then:
- Connect the game console directly to your home's first broadcaster -- the primary router. Or
- Connect the gaming device to the first mesh satellite node using a network cable. Also, in this case, it's best to use tri-band mesh hardware.
- Avoid the daisy-chain mesh setup.
- Avoid using extenders. If you must use one, make sure it's a tri-band.
Again, the idea is that the Wi-Fi signal should not have to hop wirelessly any additional time before it gets to your device -- you'll get significantly worse latency after each additional hop.
Wi-Fi performance charts
The charts below include the performance of all gaming routers mentioned above -- the top seven and their alternatives -- sorted alphabetically.
Hardware specifications
Looking to compare these top seven routers side by side? The table of hardware specifications below will help.
Note: This is a wide table -- horizontal scrolling might be necessary.
|  |
|
|
|
|
| |
|---|---|---|---|---|---|---|---|
| Full Name | MSI RadiX AXE6600 Tri-band Wi-Fi 6E Gaming Router | Asus ROG Rapture GT6 | Asus ROG Rapture GT-AXE16000 Gaming Router | TP-Link Archer AX6600 Tri-Band Wi-Fi 6 Gaming Router | Asus ROG STRIX GS-AX5400 Dual-band Gaming Router | Netgear XR1000 Nighthawk Wi-Fi 6 Pro Gaming Router | Asus RT-AX82 AX5400 Dual-Ban Wi-Fi 6 Gaming Router |
| Model | RadiX AXE6600, GRAXE66 | GT6 | GT-AXE16000 | Archer GX90 | GS-AX5400 | XR1000 | RT-AX82U |
| Wi-Fi Technology | Tri-band AXE6600 | Tri-band AX6600 | Quad-band AXE16000 | Tri-band AX6600 | Dual-band AX5400 | Dual-Band Wi-Fi 6 AX5400 | Dual-Band Wi-Fi 6 AX5400 |
| 1st Band (2.4GHz) | 2×2 AX: 574 Mbps (20/40MHz) | 2×2 AX Up to 574Mbps | 4×4 AX: Up to 1148Mbps | 2×2 AX Up to 574Mbps | 2×2 AX Up to 574Mbps | 2×2 AX Up to 574Mbps | 2×2 AX Up to 574Mbps |
| 2nd Band (5GHz) | 2×2 AX: 1201 Mbps (20/40/80MHz) | 4x4 AX Up to 4804Mbps | 4x4 AX Up to 4804Mbps | 2×2 AX Up to 1201Mbps | 4x4 AX Up to 4804Mbps | 4x4 AX Up to 4804Mbps | 4x4 AX Up to 4804Mbps |
| 3rd Band (6GHz) | 4X4 AX: 4804 Mbps (20/40/80/160MHz) | None | 4x4 AXE Up to 4804Mbps | None | None | None | None |
| 4rth Band (5GHz) | None | 4x4 AX Up to 4804Mbps | 4x4 AX Up to 4804Mbps | 4x4 AX Up to 4804Mbps | None | None | None |
| Backward Compatibility | 802.11a/b/g/n/ac | 802.11a/b/g/n/ac | 802.11a/b/g/n/ac | 802.11a/b/g/n/ac | 802.11a/b/g/n/ac | 802.11a/b/g/n/ac | 802.11a/b/g/n/ac |
| AP Mode | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Mesh-ready | No | Yes (AiMesh 2.0) | Yes (AiMesh 2.0) | Yes (OneMesh) | Yes (AiMesh 2.0) | No | Yes (AiMesh 2.0) |
| Gigabit Port | 3x LAN, 1x LAN/WAN | 3x LAN | 4x LAN | 1x LAN/WAN, 3x LAN | 4x LAN, 1x WAN | 4x LAN, 1x WAN | 4x LAN, 1x WAN |
| Multi-Gig Port | 1x 2.5Gbps WAN/LAN | 1x 2.5Gbps WAN | 1x 2.5Gbps WAN/LAN, 2x 10Gbps LAN/WAN | 1x 2.5Gbps WAN/LAN | None | None | None |
| LAN Link Aggregation | No | Yes | Yes | No | Yes | None | Yes |
| WAN Link Aggregation | No | Yes | Yes | No | Yes | None | Yes |
| Dual-WAN | No | Yes | Yes | No | Yes | None | Yes |
| USB Port | 1x USB 3.0 | 1× USB 3.0 | 1× USB 3.0, 1× USB 2.0 | 1× USB 3.0, 1× USB 2.0 | 1x USB 3.0 | 1x USB 3.0 | 1x USB 3.0 |
| Mobile App | MSI Router app | Asus Router | Asus Router | TP-Link Tether | Asus Router | Netgear Nighthawk | Asus Router |
| Gaming Features | Mystic Light Client- and App-based QoS | Aura Gaming Light Gaming Port Game Boost Gear Accelerator Mobile Game Mode OpenNAT ROG First VPN Fusion | Aura Gaming Light Gaming Port Game Boost Gear Accelerator Mobile Game Mode OpenNAT ROG First VPN Fusion WTF Gamer VPN | Fancy-looking hardware and web interface QoS | Aura Gaming Light Gaming Port Game Boost Gear Accelerator Mobile Game Mode OpenNAT ROG First VPN Fusion | DumaOS 2.0 Geo-Filter Ping Heatmap QoS | Dedicated Game Port Game Boost Open NAT Mobile Game Mode QoS Aura Lighting |
| Processing Power | Quad-core 1.8GHz CPU, 512MB DDR4 RAM, 256MB Flash | 1.7GHz tri-core CPU, 256MB Flash, 512MB DDR 4 RAM | 2.0 GHz quad-core CPU, 256MB Flash, 2GB RAM | 1.5 GHz Quad-Core CPU | 1.5 GHz Tri-core CPU, 256 MB Flash, 512 MB RAM | 1.5 GHz tri-core CPU, 256 MB Flash, 512 MB RAM | 1.5 GHz tri-core CPU, 256 MB Flash, 512 MB RAM |
| Dimensions (no antennas) | 13.3 x 8.8 x 7.8 in (338 x 224 x 198 mm) | 6.78 x 3.1 x 6.96 in (17.23 x 7.81 x 17.68 cm) | 10.4 x 10.4 x 2.9 in (26.4 x 26.4x 7.4 cm) | 8.3 × 8.3 × 2.0 in (21.2 × 21.2 × 5.18 cm) | 10.56 x 7.08 x 6.53 in (26.8 x 18 x 16 cm) | 11.61 x 7.87 x 2.51 in (29.5 x 20 x 6.4 cm) | 10.83 x 7.26 x 6.5 in (27.5 x 18.4 x 16.5 cm) |
| Weight | 2.5 lbs (1.13 kg) | 1.94 lbs (880 g) | 5.3 lbs (2.4kg) | 2.4 lbs (1.1 kg) | 1.55 lbs (701.3 g) | 1.32 lb (.6 kg) | 1.63 lbs (740 g) |
| Price (at launch) | $349.99 | $599.99 (2-pack) | $699 | $249.99 | $250 | $300 | $230 |
The final thoughts
Generally, you can play games with any router. Most routers with a good QoS feature can be manually tuned to support a particular game well.
But these gaming routers make things easier since most can automatically changes their setting when you pick a game.
Still, at the end of the day, it's your skill and the quality of your broadband connection that matter; there's only so much a router can do.
